Spectral Evolution PSR-1100f Portable Spectroradiometer

Smallest, Lightest, Full-Featured Field Portable Spectroradiometer

Spectral Evolution offers a lightweight, handheld spectroradiometer to meet the rigorous demands of the Remote Sensing community. The PSR-1100f features a durable, detachable fiber optic cable with a wide array of optional fiber mount FOV lenses and irradiance diffusers.

KEY FEATURES
SPECIFICATIONS
ACCESSORIES
APPLICATIONS
RESOURCES

The PSR-1100f offers:

320-1100nm spectral range
Rugged anodized aluminum construction for field reliability
Keypad and LCD display—can collect and store 2500 spectra without a computer
Auto-exposure and auto-dark shutter for easy, one-touch operation
Snap-in lithium-ion rechargeable battery for more than four hours of continuous use
Tag spectra with GPS, and photos with optional rugged tablet
High reliability with all photodiode arrays for stable calibration
Wireless Bluetooth interface for cable-free data connection
Lightweight, less than four pounds
Exclusive DARWin SP Data Acquisition software charts radiance, irradiance, reflectance, absorbance, or transmittance
All data is automatically saved as an ASCII file for immediate use with 3rd party software

Specifications of PSR-1100f Spectroradiometer

Model	PSR-1100f
Optics (order separately)	Removable fiber optic cable with FC-mount. Special lengths and submersible fibers available
Optional optics choices	1, 2, 3, 4, 5 , 8 and 10 degree field of view fiber mount lenses, irradiance diffusers, contact probes, leaf clips, integrating spheres and more
Spectral Range	320-1100nm
Spectral Resolution	3.0nm @ 600nm
Sampling Bandwidth	1.5nm
Spectrometer type	Tall 512 element Si photodiode array with 25µ x 2.5mm pixel dimension; fixed grating
Calibration	Factory calibrated for radiance and/or irradiance (depending upon optics choices) using NIST traceable sources
Slit	50μm
A/D Converter	16 bit
λ Reproducibility	0.1nm
λ Accuracy	0.5nm
Integration Time	8-2000ms
Internal Battery	2800mAH Li-Ion snap-in battery with AC charger; runs for >4 hours on a full charge
Shutter for dark scans	Yes
Targeting	No
Internal Memory	2500 scans in stand-alone mode
Automatic Exposure	Yes
Interface	USB and Wireless Class 1 Bluetooth (100 meter range)
Dimensions	7.0″ x 3.0″ x 6.5″ (17.78cm x 7.62cm x16.51cm)
Weight	Less than 4 pounds (1.81 kg)
Mounting	Tripod mount (¼ x 20 mounting thread)
Software	DARWin SP Data Acquisition Package (Windows compatible)
